一、TLS握手流程

客户端                          服务端
  |------ClientHello----------->| (支持的加密套件)
  |<-----ServerHello------------| (选定加密套件+证书)
  |<-----Certificate-----------| (服务端证书)
  |<-----ServerHelloDone-------| (握手完成)
  |------ClientKeyExchange----->| (加密的预主密钥)
  |------ChangeCipherSpec------>| (切换加密模式)
  |------Finished-------------->|
  |<-----ChangeCipherSpec-------|
  |<-----Finished---------------|
  |                               |
  |<====加密通信开始==============>|

二、SslContext配置

// 服务端SSL配置
SelfSignedCertificate cert = new SelfSignedCertificate();
SslContext sslCtx = SslContextBuilder
    .forServer(cert.certificate(), cert.privateKey())
    .sslProvider(SslProvider.OPENSSL)  // 优先使用OpenSSL
    .build();

// 客户端SSL配置
SslContext clientCtx = SslContextBuilder
    .forClient()
    .trustManager(InsecureTrustManagerFactory.INSTANCE)  // 仅测试用
    .build();

三、SslHandler集成

// 服务端Pipeline
pipeline.addLast(sslCtx.newHandler(ch.alloc()));  // SSL加解密
pipeline.addLast(new HttpServerCodec());           // HTTP编解码
pipeline.addLast(new HttpServerHandler());         // 业务逻辑

// 客户端Pipeline
pipeline.addLast(clientCtx.newHandler(ch.alloc(), host, port));
pipeline.addLast(new HttpClientCodec());
pipeline.addLast(new HttpClientHandler());

四、OpenSSL vs JDK SSL

启用OpenSSL：

// pom.xml
<dependency>
    <groupId>io.netty</groupId>
    <artifactId>netty-tcnative-boringssl-static</artifactId>
</dependency>

// 代码配置
.sslProvider(SslProvider.OPENSSL)

五、完整HTTPS服务器

public class HttpsServer {
    public static void main(String[] args) throws Exception {
        SelfSignedCertificate cert = new SelfSignedCertificate();
        SslContext sslCtx = SslContextBuilder
            .forServer(cert.certificate(), cert.privateKey()).build();

        EventLoopGroup boss = new NioEventLoopGroup(1);
        EventLoopGroup worker = new NioEventLoopGroup();
        try {
            new ServerBootstrap().group(boss, worker)
             .channel(NioServerSocketChannel.class)
             .childHandler(new ChannelInitializer<Channel>() {
                 protected void initChannel(Channel ch) {
                     ch.pipeline().addLast(sslCtx.newHandler(ch.alloc()));
                     ch.pipeline().addLast(new HttpServerCodec());
                     ch.pipeline().addLast(new HttpServerExpectContinueHandler());
                     ch.pipeline().addLast(new SimpleChannelInboundHandler<HttpRequest>() {
                         protected void channelRead0(ChannelHandlerContext ctx, HttpRequest req) {
                             String body = "Hello HTTPS!";
                             FullHttpResponse resp = new DefaultFullHttpResponse(
                                 HTTP_1_1, OK, ctx.alloc().buffer().writeBytes(body.getBytes()));
                             resp.headers().set(CONTENT_LENGTH, body.length());
                             resp.headers().set(CONTENT_TYPE, "text/plain");
                             ctx.writeAndFlush(resp);
                         }
                     });
                 }
             }).bind(8443).sync().channel().closeFuture().sync();
        } finally { boss.shutdownGracefully(); worker.shutdownGracefully(); }
    }
}

六、总结
